SDEC Diesel Generator

SC4H95D2    SC4H115D2
SC4H160D2  SC4H180D2
SC8D220D2  SC7H230D2
SC7H250D2  SC8D280D2
SC13G280D2  SC13G310D2
SC9D310D2    SC9D340D2
SC13G355D2  SC12E460D2
SC13G420D2  SC12E500D3
SC15G500D2  SC25G610D2
SC27G755D2  SC25G690D2
SC27G830D2  SC27G900D2
SC33W990D2  SC33W1150D2

Product Description:

Model	Genset	Diesel Engine Model	diesel power(KW/hp)	Cylinders	Boremm	Stroke(mm)	displacement (L)	Fuel consumption g/kw.h	weight(kg)	size mm L×W×H
Model	(KW/KVA)	Diesel Engine Model	diesel power(KW/hp)	Cylinders	Boremm	Stroke(mm)	displacement (L)	Fuel consumption g/kw.h	weight(kg)	size mm L×W×H
DT-50	50/62.5	SC4H95D2	68/93	4	105	124	4.3	204	800	18007301300
DT-75	75/94	SC4H115D2	86/117	4	105	124	4.3	204	900	19008001300
DT-100	100/125	SC4H160D2	116/158	4	105	124	4.3	198	1000	21008501300
DT-120	120/150	SC4H180D2	132/180	4	105	124	4.3	198	1000	21008501300
DT-150	150/187.5	SC8D220D2	160/218	6	114	135	8.28	198	1200	23008501350
DT-150	150/187.5	SC7H230D2	170/231	6	105	124	6.5	193	1500	25008901400
DT-150	150/187.5	SC7H250D2	185/252	6	105	124	6.5	193	1580	25008901400
DT-200	200/250	SC8D280D2	204/278	6	114	135	8.28	200	1600	25008901400
DT-200	200/250	SC13G280D2	206/280	6	135	150	12.88	200	2270	25008901400
DT-200	200/250	SC13G310D2	227/309	6	135	150	12.88	200	2300	25008901400
DT-200	200/250	SC9D310D2	228/310	6	114	144	8.82	200	1600	25008901350
DT-250	250/312.5	SC9D340D2	255/347	6	114	144	8.82	195	1600	25008901350
DT-250	250/312.5	SC13G355D2	260/354	6	135	150	12.88	200	2300	25008901400
DT-300	300/375	SC12E460D2	338/460	6	128	153	11.8	192	3000	29009001800
DT-300	300/375	SC13G420D2	308/419	6	135	150	12.88	200	2650	300012501800
DT-350	350/437.5	SC12E500D3	370/503	6	128	153	11.8	192	3000	29009001800
DT-350	350/437.5	SC15G500D2	373/507	6	135	165	14.16	200	3000	29009001800
DT-400	400/500	SC25G610D2	445/605	12	135	150	25.8	202	3500	320010001800
DT-500	500/625	SC27G755D2	555/755	12	135	155	26.6	202	3600	350010001800
DT-500	500/625	SC25G690D2	505/687	12	135	150	25.8	202	3600	350010001800
DT-600	600/750	SC27G830D2	610/830	12	135	155	26.6	202	4000	360015202100
DT-600	600/750	SC27G900D2	662/900	12	135	155	26.6	202	4000	360015202100
DT-700	700/875	SC33W990D2	726/988	6	180	215	32.8	215	4500	360018002100
DT-800	800/1000	SC33W1150D2	860/1170	6	180	215	32.8	215	6500	370016502200

More Details Information Please Contact Us

Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Ricardo Lovol Cumminss...and so on

Genset Features

B and F series product
Original European Technology, Independent R and D.
Gen-sets Power Matching Coefficient.
Matched with Professional High-temperature Radiator.
Professional Application and Integration Capabilities.
Option Automation, Auto-switch, Auto-parallel Connection and other Functions Freely.
Key Components of The Controller, Circuit Breakers, Generators for the Domestic and International Famous
Strong power,high reliability
Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Cummins
