380HP Weichai WP10.380E32 Diesel Engine

WP10.270
WP10.290
WP10.310
WP10.340
WP10.375
WP10.380

Product Description:

Engine model	WP10.380E32	Number of valves per cylinder	4
Rated power	380	Air inlet system	Turbocharged & Inter-cooling
Rated speed	2200 rpm	Economic Fuel Consumpition Ratio	189g/kW.h
Cylinder diameter/stroke	126×130 mm	Engine Type	In-line
Displacement:	9.726 L	Cooling Method	Water cooled
Cylinder QTY	6	Stroke	4
Fuel System	Direct injection	Ignition order	1-5-3-6-2-4
Maximum torque	1600 N.m	Weight	875kg
Maximum torque speed	1500-1800 rpm	Dimension	1525×730×1063mm

WEICHAI WP10 Series Diesel Engine For Truck
Type	Rate Power (HP)	Speed (rpm/min)	Cylinders No.-Bore*Stroke (mm)	Intake way	Economic Fuel Consumption	Starting Method	Net weight (kg)	Dimension LWH(mm)
WP10.270	270	2200	6-126*130	Turbo&Inter-cooling	198g/kw.h	Electrical	875	1525×730×1063mm
WP10.290	290	2200	6-126*130	Turbo&Inter-cooling	198g/kw.h	Electrical	875	1525×730×1063mm
WP10.310	310	2200	6-126*130	Turbo&Inter-cooling	198g/kw.h	Electrical	875	1525×730×1063mm
WP10.340	340	2200	6-126*130	Turbo&Inter-cooling	198g/kw.h	Electrical	875	1525×730×1063mm
WP10.375	375	2200	6-126*130	Turbo&Inter-cooling	198g/kw.h	Electrical	875	1525×730×1063mm
WP10.380	380	2200	6-126*130	Turbo&Inter-cooling	198g/kw.h	Electrical	875	1525×730×106
